| Equipment |
Content Covered |
| CNC Milling Machine (7.5 kW, ATC with 20 tool magazine, accuracy 10 µ) |
Introduction to CNC & Elements of the Machine |
| CNC Lathe Machine (5.5 kW, 8-station turret, accuracy 5 µ) |
Basics of CNC Programming |
| CNC Controller & Control Panel |
Coordinate System & Machine Modes (Jog, Auto, MDI, MPG, SBK, DRY) |
| Tooling & Work Holding Devices |
Setting & Operation of CNC Machines |
| CAD/CAM Software |
Manual Programming & Computer Assisted Programming |
| CNC Programming Interface |
G & M Codes for CNC Programming |
| CNC Inspection Tools |
Inspection & Dimensional Control of Workpiece |
| Coordinate Measuring Machine (CMM) |
Precision Measurement & Quality Inspection |
| Kistler Dynamometer 9272 |
Cutting Force Measurement & Analysis |
| SKF Microlog Analyzer |
Vibration Analysis & Condition Monitoring |
| Wire-Cut EDM Machine |
Advanced Manufacturing Process Demonstration |
